BF869

€ 2,00
Omschrijving

BF869

 Type Designator: BF869
   Material of Transistor: Si
   Polarity: NPN
Absolute Maximum Ratings

   Maximum Collector Power Dissipation (Pc): 1.6 W
   Maximum Collector-Base Voltage |Vcb|: 250 V
   Maximum Collector-Emitter Voltage |Vce|: 250 V
   Maximum Emitter-Base Voltage |Veb|: 5 V
   Maximum Collector Current |Ic max|: 0.1 A
   Max. Operating Junction Temperature (Tj): 150 °C
Electrical Characteristics

   Transition Frequency (ft): 60 MHz
   Collector Capacitance (Cc): 2 pF
   Forward Current Transfer Ratio (hFE), MIN: 50
